How to use a Multimeter to Determine if You Have a Bad Controller, Valve, or a Wiring Problem

Multimeters are handy for testing many kinds of wiring or electrical problems. Considering their versatility they are amazingly affordable. While they vary in complexity from basic to how-many-functions-did-you-say-it-had levels, we only need the basic here.

The most important thing to know if you have never read one: read the instructions. Two or three times. Make sure you understand the symbols and connections. There are few things as interesting as trying to test a 110AC wall outlet when your meter is set for low voltage DC. You’ll know you messed up.

Your problem: your valve won’t come on. And we don’t know why. There are really three electrical reasons it might not: bad controller, bad wires, bad solenoid. We always start with the simplest test first.

When testing to see whether our problem is with the controller the question we are really asking is “does the controller put power out to the valve?” To check this we’ll simply test two connections inside the controller. So open your controller so that you can see where the valve wires connect. You should have one COMMON, usually white, and any number of zones, usually red but any color is possible.

Turn your Multimeter to the proper VAC setting. Turn the problem zone on with the manual start on the controller. Here we will say it is zone 1. Touch one lead to the common and one lead to the zone 1 wire/screw. You should get around 24V. Usually 22 to 28 works. If you get lower than 22 you have a problem. Check another zone even though the other zones are working properly. It only takes a second and verifies that the Mulitmeter is set and functioning correctly.

Let’s assume the voltage is good. Now let’s check the wires. We’ll check for continuity, which is testing the ohms or resistance of the zone. Turn to the Ohms setting. It might look like (Ω). Check your manual to be sure. This will test for a short in the circuit. First, turn off the controller. You don’t want to check resistance with a live circuit. Disconnect the zone wire. Place one lead on the common terminal and one lead on the zone wire/screw. Depending on the valve brand you should get a reading from 20-60 ohms; every manufacture’s valves will have a slightly different reading. Low signals indicate trouble with the solenoid. On the other hand, any reading above 60 means you have a wiring problem, either stripped insulation, nicked wire or bad connection. Wire problems can be involved so, before we get the shovel out, let’s go test the solenoid and other wire end. Before you start walking, manually turn the zone on again.

At the valve disconnect the wires from the valve. Now set your solenoid back to the proper VAC setting. Touch one lead to the common and one to the power. You should get the same reading here (24v) as you did at the controller. If you continuity test you did in the last paragraph failed you probably won’t. We are double checking the wire to make sure of problems before we tell you to start digging.

If all that passes we are left with two things: either the twist connection for the controller wire to valve was bad or the solenoid is bad. Let’s test the solenoid first. Go back to your Ohms setting. Touch one lead to one wire from the solenoid, the other lead to the other. Again, you should get between 20 and 60 ohms. If not, replace the solenoid. If it passes the only thing left is a bad connection. Re-connect the wires using waterproof connectors, see if it now activates. Remember that the controller has that zone on so 24V should be going through those wires.  Careful. Might want to turn the zone off then reconnect and test.

If you have not found the problem at this time there may be a mechanical problem in the valve. You can replace the valve but first just open it and clean the internals.

We tested the controller for output, the wire for continuity, the connections for, well, connection and the solenoid for resistance. All with the handy-dandy Mulitmeter.

Solenoid Chatterer and Wire LocatorIf you plan on doing this on a regular basis, consider the Pro 48.   The Pro48 TechTool incorporates a solenoid activator to hold valves open; a chatterer to locate lost valves; a continuity checker to identify cut or shorted wires or solenoids; and a 24 VAC detector to ensure proper clock power output. Operation is simple as LEDs indicate tests and conditions. Truly a workhorse product for any landscape professional. This, along with a valve locator, can be purchased or rented at Sprinkler Warehouse.

Apr 25 2012

Now You See it, Now You…Wait! Where Did it Go?

It used to be that the only things certain in life are death and taxes.  I’m going to add a third thing: someone wants your backflow.  Not in the manner of   “I want to buy Girl Scout cookies.”  This is in the line of “I want to steal that backflow and sell it for money.”  Someone is looking to you to pay their bills. After all, charity starts at home. Your home, your backflow, your expense.

Three things are combining to cause trouble. The economy is down, which means unemployment is up. Besides the standard, everyday crook, people who would never consider theft before now turn to it to pay bills. The second thing is continuing global population growth. More people means more resources are needed to support them. That means metal for tools. The final thing is the growth of formerly agricultural economies into modern, technology driven countries. Technology requires metals of all sorts.  Roll all this together and prices for scrap metals are high and rising. Your backflow is worth noticeable money to someone.

You lose in two ways. The most obvious is you have to pay to get the backflow replaced, parts and labor. The second is the water you have to pay for when they steal the backflow and your system starts pouring thousands of gallons out to the street.  Not to mention the inconvenience of going without household water if you don’t have a cut off valve on your system.  The best thing to do is stop the theft from ever happening.

Artificial rock backflow preventer coverOne way is to use the Jedi mind trick: “you only thought you saw a backflow here…you are obviously wrong…there is no backflow here…” This trick works best if you supplement it with a Dekorra rock enclosure. These are fake boulders designed to cover your backflow and make it blend into the landscaping. Who notices a rock? There’s not a lot of demand for stolen boulders. The enclosures cover the backflow, are available in standard, insulated and heated options, two finishes and a multitude of sizes. Since rocks are used in landscaping already it doesn’t scream out “hidden backflow.”  It says “landscaping feature.”

If you want the cover and/or insulation but aren’t a Jedi you can use the standard backflow enclosure. They provide the same weather protection as the rock enclosures without the camouflage effect. They do add the option of a side grid for quick visual inspections.

These also add one more step to getting to your backflow. This adds time and your average thief wants a short, quick job. Adding time discourages theft.

If adding time and effort discourages theft, then the other option is making the backflow very hard to get. Use the Gorilla Cage. Sounds like a visit to the zoo, doesn’t it? Except this cage keeps animals (crooks) out and peace and serenity in. The cage is made of strong steel tubing, angle and expanded metal with a guard to prevent the padlock from be cut by bolt cutters. Notice how the lock guard completely surrounds the lock? You don’t  The cage is bolted down to a concrete pad making for strong unitized construction. The form is even provided with the cage. Once unlocked they allow easy access for servicing or testing of the back flow.

No one will open these with a simple hammer or hacksaw. Bolt cutters won’t work. A cutting torch will but that’s a little more obvious than crooks want to be. Most crooks will pass these by and go to the next unprotected backflow they can find.

Whether you protect your backflow by hiding it or locking it away, the important things is that it stays in your yard, not someone’s truck.

Apr 3 2012

Valve Manifolds and Why You Want Them

Think about your average irrigation system. Say five zones made up of spray heads and  rotors. Front yard, back yard, side yard. Pretty much what you see everywhere.sample diagram of where to place valves in a property This means that there are five valves in the system. Now, there are two ways you can install valves. Both work. You can install them in each zone, as illustrated:

This works fine but someday, when you need to find the valve for repair, it may be overgrown, have a dog house on it or have simply disappeared.  Plus you are spending money on seven valve boxes and all that wire to go to all those valves.

sample diagram of where to place valves in yard
This is another way to place your valves. This keeps all the valves in a simple to find and maintain area and you would only need two valve boxes. This is called clustering. It makes long term maintenance far easier. You can also cluster them in out of the way, low traffic areas, minimizing risk of damage.

The easiest way to install this is with pre-made manifolds. Two of the most popular are the Action Machine and Dura brands. They are both available in different sizes and are expandable for future growth.

So what’s the difference? Why is one labeled Premium and one Standard?  There are two main differences. The first is the pressure rating. The Premium has a pressure rating of 235 psi @73o. The standard has a rating of 150 psi. Again, either will work for the vast majority of installations.

The second difference is more practical. Understand that once these are installed you don’t touch them again until something goes wrong, usually years down the line. At that time they will be dirty, wet, muddy and possibly underwater. Now you want anything that will make it easier to work on the system. The Action Machine coupling has a much larger and more defined grip on the ring. The larger grip makes a world of difference when it’s wet and slippery. Saves time, skin and frustration.

Either manifold will work fine.  You might wonder at this time why you can’t just build your own. After all, PVC is cheap and you will be working with it already.  No reason you can’t and it will work. However, the premium manifolds are made of Schedule 80 PVC, much stronger than the Schedule 40 you will be working with. Add the fact that the manifold backbone is one piece and you gain both rigidity and a guaranteed straight line.  Finally, the time and effort you spend measuring, cutting and gluing your parts together is worth something. Save that time for relaxing after the job is done.   Pre-made is best by far.

MORE INFORMATION

For any irrigation system questions please visit us at Sprinkler Warehouse.

Mar 27 2012

Why Just Florida?

What does Florida know about irrigation that the rest of the country doesn’t? Why do they use more of a surprisingly simple and effective device than any other state? Especially when you consider how much money this device can save? Do I sound like a late-night infomercial yet?

Take a look at the K-Rain Indexing valve. This valve lets you irrigate up to six zones without installing and wiring six different valves.  Each time the waters turns off and back on the valve waters a different zone.  There is a really smart disc inside that advances to the next zone when pressure drops. Water zone one, stop water for a few moments, start water, water zone two, etc. Automatically.

Yes, it looks strange. We don’t care: it works great.  These are commonly installed either on a direct feed from a pump or downstream of a single solenoid valve. The way it works is simple. Say you are using a solenoid valve. The valve comes on. Zone one on the index valve opens and water goes to zone one. The solenoid valve turns off. The index resets to zone two. The master valve comes on, zone two waters. Repeat for three through six. These are available with either four or six outlets; a six outlet is shown.

If you are working off a pump then each time the pump cycles the valve advances.  This completely eliminates the need for a solenoid valve and the related wiring and controller.  These valves work with flows as low as 10 GPM and at pressures of 25 to 75 PSI.

A great feature is the possibility of future expansion. Say you only have two zones but plan on expanding. You can get the four outlet model with a two zone cam. Down the line you can change the cam out to allow for three or four zones. Just keep the two future outlets capped off until then. The four zone outlet pattern is shown; the six zone is similar.

Here we have one valve that eliminates the need for any solenoid valves if working directly off a pump and eliminates the need for all but one if working off a municipal system supply. No wonder Florida loves it. Money saved on valves and money saved on wiring. Labor saved by not installing the other valves and wiring. Labor saved = money saved.  Order now. Operators are standing by. Or the website is, anyway. And if you order in the next 10 minutes you’ll have plenty of time to do something else today! So hurry!

Mar 5 2012

Teflon Tape and How To Use It

Teflon Pipe TapeTeflon® tape (polytetrafluoroethylene, or PTFE), AKA plumber’s tape, is a thin film used to seal pipe threads. The tape is durable, flexible, and fills in the minor imperfections in the threads to seal leaks.

To use, hold one end of the tape against at the start of the pipe threads/end of pipe and start wrapping opposite of the direction of the threads, keeping the tape flat. Pull the tape Wrapping Pipe with Teflon Tapetightly into the threads but not so tightly that the threads cut through. Keep going in a flat uniform manner until you come to the ends of the threads/pipe. Now thread the pipe in carefully and you’ll have a good seal.

You might want more than one layer but generally not more than two or three. If you are using drastically different materials, such as copper or brass to PVC, you may need extra but that is unlikely. Too much tape is as bad as too little. It will prevent a good seal. With the proper amount the pipe should thread together smoothly, sealing all gaps in the thread.

When do you not use plumber’s tape?

This tape is only effective on tapered threads as it uses compression to form the seal. Fortunately, the vast majority of the connections you make in irrigation will be with National Pipe Thread Tapered Thread, or NPT, and this tape will work well.

Many will tell you that brass to brass fittings are self sealing. In one manner they are but it takes an experienced professional to know which ones will work. You risk a leak if you are not sure you have the correct condition. Tape is cheap insurance. Brass fitting threads also tend to be extra sharp, especially on the smaller pieces, and may cut through the tape and ruin the seal. In this extra care is needed. In extreme cases you might need pipe dope but that is rare. The general connection involving brass in an irrigation system is with the backflow. Plumbers tape should work just fine there.

Feb 21 2012

PVC Pipe Leak Repair

Irrigation systems are designed to put water where it is needed in an effective manner. When water appears in new, unexpected places there is a good chance you have a leak. Fortunately, with most systems being made out of PVC, repairing the leak is relatively simple. We’ll go over a number of products and explain how each works, including one that handles galvanized. The first step is to make sure the system is turned off. Having a system come on while you are kneeling over it repairing a leak is an experience to avoid.

There are two important things to remember when you dig up the broken pipe. The first is BE CAREFUL. Don’t try to get all the dirt in one scoop. First, it’s bad for your back. Second, if you push too hard and end up hitting the pipe you could cause a brand new leak. When digging up a pipe it is best to take smaller, careful cuts to ensure that no other damage occurs.

Second, when you find the damaged area make sure to dig a few inches deeper and to each side. The system will have water in the pipe, waiting to get out. This water will want to flow out the handy opening you have just revealed. Digging extra deep allows for the water to drain below the pipe. Also, regardless of the type of patch you put in, you will need clear access to the bottom of the pipe. If you cannot dig deep enough to bring the water level down you will have to bail or pump it out. You will also need to dig to each side a little to give yourself working room for the repair.

Once you have found the leak you need to decide on what type of repair kit you need. All except one needs PVC primer and cement. We’ll discuss the exception first.

Compression FittingsPVC Compression Fitting

This can be used on either PVC or galvanized pipe. A compression fitting relies on pressure on a rubber seal to stop the leak. The compression collar and “O” ring slip on the pipe, the pipe slips in both ends, the collar is tightened and the leak is repaired. They have a number of advantages. Not needing cement means the pipe does not have to be completely dry to repair. If you need to you can do the repair while the water is running. Don’t laugh. It happens. They are quick to install and dependable. The primary disadvantage is they do not work for leaks at or near a fitting. For more information click HERE.

Leak Stopper Rings

Leak Stopper Rings

If you have a small leak at the junction of a pipe into a fitting, but the pipe and fitting are not cracked, it’s possible you have an area that was not completely glued. Rather than cutting out the entire fitting for a minor leak you can use a Leak Stopper Ring. These go around the pipe, both the ring and pipe are primed and glued, then the ring is pushed hard against the fitting. The glue creates a permanent bond with the ring, the pipe and the fitting, stopping the leak. More information is HERE.

Snapper Repair CouplingsPVC SnapLock Repair Fitting

Snapper Repair Couplings are the Duct Tape of PVC: just wrap it up and it will hold. Snapper Repair Couplings are like two halves of pipe split lengthwise. A great advantage of these is you do not need to cut the pipe. The inside of both halves of the coupling and the outside of damaged area of the pipe are primed and cemented. The halves are snapped in place around the break and you have a permanent repair. More information is HERE.

Pipe Dream FittingsPIPE Dream PVC Repair Fitting

Like many brilliant ideas this one is deceptively simple. Fittings and couplings tend to be a standard size. If you have a broken line you need to cut the break out. Now you need to reconnect the ends. To do this with standard fittings and pipe you must cut out a larger section of pipe, install fittings and install the new pipe. More work, more gluing. This is particularly hard if a corner or T fitting is involved. The simple idea of Pipe Dream is make the fitting extra long. Because they are longer than the standard coupler, elbow or tee Pipe Dream is able to completely cover the damaged area without the need for additional parts or supplies. Simple. More information is HERE.

Kwik-Repair TeesPVC Kwik-Repair Tee

This is another “why didn’t I think of that” product. KwikRepair Tees are simply a replacement section of pipe with the slip fit couplings already installed. The couplings are pushed in to the shortest length. The broken pipe section is cut out to a matching length. The KwikRepair Tee is then put in place, the Tee and pipe are primed and cemented, and the couplings are pulled out to full length. Job done. More information HERE.

Quik-Fix Telescopic Repair CouplingPVC Quick-Fix Telescopic Repair Coupling

A Quik-Fix coupling is simple and quick. Simply cut out section of broken pipe slightly longer than compressed Quik-Fix, apply primer and glue to fittings and expand Quik-Fix to fill the gap. Leak repaired. A great advantage is, because the fitting expands, there is some small room for error in how big a section of pipe you remove. For example, if you cut 1” less than the suggested length the Quik-Fix will still work. You just don’t expand it all the way. However, don’t cut too long, they don’t stretch. More information HERE.

Pipe FixPVC Pipe Fix Repair Tee

Pipe fix give you more options in your repair. It is a section of replacement pipe with the fittings already in place. This provides a one piece, no hunting for parts, repair. It also offers the option of a straight repair or adding a Tee joint, allowing replacement of a failed Tee or the option of installing a new line. More information HERE.

Primer and CementFast Setting PVC Cement

Regardless of which method you choose all of these require a quality primer and cement, excluding the compression coupling. To find what we recommend, go HERE.

For More Information

For more information about anything involving irrigation, please visit us at www.SprinklerWarehouse.com.

Feb 17 2012

But it is cheaper this way…

A fact: some parts are cheaper than others. I’ll give you another fact: sometimes the cheaper part is as good as or better than the more expensive part. Why then wouldn’t you save money by buying the cheaper part?

There are a number of ways to save money. Sometimes it is by buying the least expensive part. Other times it may be by buying the most expensive part. Sometimes it is by cutting coupons. It’s a mixed bag. So how do you get the most return on your dollar? Simple: buy the most efficient product for your system and your life style; the product that works best with your system, providing the best service over a period of time. But best doesn’t only mean mechanically. It means best as in “efficient mechanical performance with the fewest demands on the owner’s time and effort.”

Nozzles

Let’s talk about sprinkler nozzles for a moment. We’ll compare Rain Bird, Hunter and K-Rain in a 12’, full circle spray. There is about a $0.50 spread from low to high. They all work; they all put out 12’ of water in a full circle. The yard gets wet.K-Rain Sprinkler Nozzle

The problem is the Toro nozzle puts out 2.19 gallons per minute (GPM). The other two put out around 2.65 GPM. So if you have a system with Toro nozzles and put in one Hunter or Rain Bird nozzle then that area will be over watered, harming the grass, water will be wasted and you will pay for that wasted water. Conversely, if you put a Toro head on a Hunter zone then that area will be under watered, may start to suffer and you’ll wonder why. The least expensive is whatever is the most efficient for your design. To find the correct nozzle for your system, go HERE.

Rotors

Let’s look at rotors for a moment. We’ll compare the Hunter PGP against the K-Rain RPS75. These two rotors are almost identical in design. However, the nozzles they come with are not. If you have 40 psi of water pressure and you need to spray 40’ their water volume differs. One uses 3.0 GPM, one uses 4.3 GPM. Your system will be designed for one or the other. If you mix them then one area will be over watered or another will be under watered. Cost to you if you install the wrong ones? Lots of head scratching and frustration as you watch lawn problems develop.K-Rain Rotor

Remember, a well designed system will water your yard in the most economical and efficient manner possible. As in many things, consistency and uniformity are important. When you change the design by mixing in unmatched parts just to save a few dollars, or more expensive parts because you like the brand name, you can cost yourself money, time and stress wondering why your yard is no longer as healthy as it was.

More Information

As always, you can come to Sprinkler Warehouse for more information. We’ll be glad to help.

Jul 2 2010

How to Choose an Irrigation Controller

Sprinkler System Guide

Irrigation controllers are essential components of a Irrigation Sprinkler System.When DIY sprinkler system, the following article can help you better understand how to choose, install and replace a controller / timer.

What is an Irrigation Controller?

Hunter Pro-C Timer

Hunter Pro-C Timer

Irrigation controllers, also known as irrigation timers or lawn sprinkler system timers, are the nerve centers or brains of the sprinkler system. Sprinkler system timers send electric signals to the irrigation valves. The valves regulate the flow of water to the sprinkler system.

Irrigation Sprinkler System timers are the devices that allow you to set a watering schedule to meet your needs. You can set the days you want to water, the time of day you want the sprinklers to come on, and how long you want them to apply water.

Sprinkler system controllers may be mechanical, partly automatic, or fully automatic. Although irrigation sprinkler system timers are largely maintenance-free, the home or property owner might wish to upgrade and replace irrigation controllers or install irrigation controller parts or extra features. Sprinkler timer installation or replacement is very straightforward and easy and can be done by either the homeowner or by an irrigation professional.

How to Choose an Irrigation Controller / Timer

The only important decisions you need to make when selecting a controller / timer are as follows:

  1. Controller mounting location: indoor or outdoor
  2. Number of stations or zones – must be at least as many zones or areas your sprinkler system is broken up into.
  3. Number of programs (1, 2, 3, or 4) – should have at least 2 or more programs to give you the watering flexibility you want or need. The programs on a controller are very different from the number of stations on a controller. This is explained below.

IMPORTANT: The rest of the features you can choose from on a controller are just for added benefits or increased flexibility.

Indoor vs. Outdoor models
Sprinkler system controllers come in a wide range of makes and models. Choose lawn sprinkler system timers depending on the size of the sprinkler system and the user’s needs. Lawn sprinkler system timers come in two different types: indoor models and outdoor models. Indoor sprinkler system timers need to be sheltered from weather, and can be conveniently plugged directly into a 110-volt outlet. This is because they come with an external transformer as part of the plug-in cord that converts the 110-volts to 18 volts. Typical locations for mounting indoor timers are in the garage, building, covered patio, shed, pump house, closet, etc. Outdoor lawn sprinkler system timers are convenient, weather resistant, durable, and typically need to be hard wired for power instead of plugged into a 110-volt outlet. This is because the transformer is located inside the protective weather resistant cabinet and it is assumed that the electrical connection will need to be weather resistant also.

Outdoor controllers can be used as indoor controllers just by adding a pig tail (3 prong plug and power cord) to the power wires of the timer. People do this all the time to be able to get all the benefits of an outdoor timer with a weather resistant cabinet and typically all kinds of added features. An example of this is the Hunter ICC model controller which is one of Hunter’s best controllers. It has so many nice features that people will just add a pig-tail and make it an indoor timer.

Controller Stations
Typically, residential systems use irrigation controllers with 2 to 9 stations, while systems for commercial or public properties can have 32 – 48 stations or more. Each station regulates one zone or area of the lawn sprinkler system. When selecting irrigation controllers, know how many stations the system needs. Choose a sprinkler timer with extra stations, in case of later expansion.

Controller Programs
The number of programs a controller or timer typically has can range from 1 up to as many as 4. They are usually labeled as Program A, B, C, and D. Some controllers only have 1 program while most have at least 2 or more. A program is a set of watering instructions for stations that will run on the same days. When you set up Program A on the controller, you are setting the days you want to water, the time of day you want to start watering, and how long you want to water. If you have a controller with two programs, the lawn areas can be set up to be watered every day on one program and the flowerbeds and shrubs every other day on the second program. When a controller starts a program, it will go through the entire program before stopping or repeating the program.

Types of Controllers – Mechanical or Solid-State (Digital)

Some irrigation controllers are fully digital, including easy touch screen features. Digital sprinkler system controllers with basic features are suited to a more conservative budget. Other lawn sprinkler system controllers have an array of features and options for convenience and ease of operation.

Mechanical sprinkler system timers use manually-operated sliders and switches for programming. An electromechanical controller uses both an electric clock and mechanical switching. That is to say, they are made of a motor, wheels, dials, gears, and pins. These controllers are typically, easy to understand how to operate and program, and are less susceptible to power spikes and surges, but are much more limited in features than solid-state digital irrigation controllers.

Solid-State controllers have digital readout screen, have no moving parts, and use integrated circuits for the clock, memory and control features. These controllers are adaptable, offering many more features at a reasonable cost. More advanced Solid-State controllers such as Smart Controllers can adjust the watering schedule automatically throughout the year. Still other controllers operate solely on battery power, for areas with limited or no electricity. Solar-powered controllers are also available.

Features Available on a Controller

Some controllers come fully loaded with features for efficiency and convenience of operation. In others, extra features may be optional. Key features available on a controller can include:

  • Clock and calendar settings
    The user can program watering times, control watering cycles, and make seasonal adjustments.
  • Manual start and manual station operation
    The user can operate the stations or start the automatic cycle without affecting the programmed start time. This is helpful when you need to do some maintenance to your system. This feature makes it easier to check for leaks, misaligned or broken sprinkler heads and even perform basic tune-ups steps such as adjust spray patters and replace nozzles.
  • Master Switch
    The master switch overrides the automatic functions of the stations.
  • Master Valve Control
    The master valve prevents flow to the system, in case of water problems or system failure.
  • Station Omission
    The user chooses which stations operate, and which do not.
  • Pump Start Lead
    This turns on a pump start relay whenever a station activates, to combine irrigation and pump control. A Pump Start Relay is an electronic device that uses a signal current from the irrigation controller to activate a pump to provide water to the irrigation system. Never connect the controller directly to a pump as damage to the controller will result.
  • Rain Sensor
    A rain sensor shuts down the irrigation system if it detects rain. The purpose of a rain sensor is to stop watering when precipitation is sufficient. Most controllers allow for a sensor to be connected directly to the controller and allow you to easily override the sensor by using a Rain Sensor Bypass switch on the controller.
  • Battery backup
    The controller reverts to battery power in case of power interruption or outage.The battery typically will just allow the timer to maintain the time, date, and watering schedule. On some controllers it allows the user to program the controller without AC power. IMPORTANT: watering will not occur without AC power. The battery only keeps the time, date, and watering schedule in memory until the AC power is restored or the battery dies.
  • Non-Volatile Memory
    The controller retains its program data without a battery, even if the power fails.  The non-volatile memory allows the timer to maintain the time, date, and watering schedule indefinitely. IMPORTANT: watering will not occur without AC power.
  • Delay
    The delay feature allows time for valves to close fully in one zone, before opening the valves in another zone.

Where to Buy a Controller / Timer

For more information about irrigation controllers, options and features, or to purchase a new irrigation controller or sprinkler timer, go to www.SprinklerWarehouse.com.
If you need more irrigation help, questions about irrigation system repair, or how to install a spinkler system, please visit IrrigationRepair.com

Jul 2 2010

Types of Irrigation Valves

Irrigation / Lawn Sprinkler System Valves – What Are They

Irrigation Sprinkler System Guide
Irrigation valves or lawn sprinkler valves are an essential component of lawn sprinkler systems. They control the flow of water in lawn sprinkler systems. Sprinkler system valves come in a variety of models, including below ground inline valves and above ground anti-siphon valves.

Available in solid brass or durable plastic, sprinkler valves operate from a manifold above or below ground to regulate water flow to the lawn sprinklers.

Anti-Spihon Valve vs. Inline Valve

Shop for Anti-Spihon Valve or Inline Valves

Lawn sprinkler systems may be manual or automatic. Automatic lawn sprinkler systems consist of the controller / timer, the sprinkler valves, the pipes, and the lawn sprinklers. Each valve controls a different zone, or area, of the lawn sprinkler system. The controller sends electric low voltage (24 volt AC) signals to the valves, telling them to open or close.

Sprinkler valves come in many different styles. Globe or angle irrigation valves work with a separate backflow preventer, and anti-siphon valves have the backflow preventer built-in. Rain Bird valves, Toro valves, Hunter valves, Irritrol valves and Weathermatic valves are all reliable, well-known products that, with proper maintenance, will last for many years.

Irrigation Valves – Types of Valves and What They Are Used For Shut-off Valves

Emergency shut-off valves stop the flow of water to the irrigation system. If repairs are needed to the sprinkler system valves or any other part of the irrigation system, the shut-off valve prevents the need to turn off the entire water system to the house or what ever else the water feeds.

Emergency shut off valve: You should install this sprinkler system valve as close to the water source as possible and should be the same size as the pipe you are installing it on. If you do not install this valve, you will have to shut the water off to the entire house when you want to make repairs or work on the irrigation line. You only need to install one of these shut off valves for your irrigation system and it will either be installed under ground in a valve box or in the basement depending on where your water supply connection is located.

If you are using a water meter from the city as your source of water, it is best to tee off the pipe coming out of the water meter (the one headed to feed the house) as close to the meter as possible and use the tee to start the water supply to the sprinkler system. In this case, you would install the shut off valve close to the tee on the line headed to feed the sprinkler system. Some people will put the tee close to the meter but then install the shut off valve just before the backflow device which may be installed on the side of the house. If you are in an area that freezes and you will be using the basement water supply piping as your sprinkler system water supply, install the shut off valve in the basement on the piping before the backflow device.

The most popular valves used for this purpose are the gate valve, ball valve, disc valve or butterfly valve. The gate valves are the most inexpensive and tend to NOT Close completely plus they are typically metal and corrode quickly making it difficult if not impossible to use. Your best bet is to use a PVC ball valve (highly recommended) since they are a more reliable choice. They close completely and they do not corrode or rust which means you should always be able to open and close them easily even when buried under ground in a valve box.

Control Valves (as known as Zone Valves)

Irrigation control valves are used to turn the irrigation system on and off and there are two different types to choose from:
1.) Globe and Angle Valves
2.) Anti-Siphon Valves

The globe and angle valves come in any size and are usually installed under the ground or in a vault or valve box. Since there is not a backflow preventer attached as part of the valve, you will need to add that separately. This is the most common type used in sprinkler systems. However, you may choose to use the anti-siphon valve, which comes only in 3/4- and 1-inch sizes and comes complete with a backflow preventer. The anti-siphon valve absolutely must be installed above the ground and must also be 6 inches higher than that of the highest sprinkler head.

Valves come in brass and plastic; the most common ones used today are the plastic ones. The brass valves will ultimately last longer if installed in the sunlight. Both types are reliable for an automatic system, but for manual systems the manual brass valve is the best choice because it lasts much longer. Valves today are fairly maintenance free.

As for pressure losses and valve size, the automatic valves should be sized based on the manufacturer’s flow range chart and will not necessarily be the same size as the pipe. However, it is more common that it will be the same size as the pipe it is installed on. A manual valve is much more adaptable than the automatic and you do not have to depend on electricity to power it, rather it is done manually, hence the name. A manual irrigation control valve needs to be either an angle or globe type with replaceable rubber seals and not the gate type as the gate valve is not made to be opened and closed regularly.

Above Ground Anti-Siphon Valves

Anti-siphon valves have a built-in backflow preventer to keep irrigation water from washing back into the household’s main water supply. Use Anti-Siphon valves in locations where the use of a pressure vacuum breaker (PVB) or double check valve is not required by city codes. Some areas of the country, such as in California and Arizona, require backflow prevention for every zone. Check your local city codes to determine what type of valves are required. The Anti-Siphon valve is a combination valve that has an atmospheric vacuum breaker and an electronic control valve all in one unit. It provides backflow prevention on every zone, saving costs by eliminating the need for a separate backflow preventer. Anti-Siphon valves are installed above ground and will prevent back flow if properly installed. Anti-Siphon valves should always be installed at least 6” above the highest head on the valve line, and should never have another valve installed further down the line from the main valve

Below Ground Inline Valves

These valves are often globe valves or angle valves. Inline valves are installed underground, protected by a valve box. Below ground inline valves require a separate backflow preventer, installed to meet local bylaws and regulations. However, the great thing about inline valves is that they are typically less expensive than anti-siphon valves and you can install them in the middle of each zone (or section) of your sprinkler system which keeps the pressure loss in the zone more balanced and uniform. Furthermore, you save money on pipe since you end up with one mainline traveling through your yard supplying all you valves instead of having multiple runs of pipe in the same trench heading from the anti-siphon valve manifold to each zone. Plus you only need one backflow preventer device protecting the whole sprinkler system instead of paying for one on each anti-siphon valve. Using a single backflow device with inline valves is a better way of installing your system and it will last longer than the anti-siphon valve plastic backflow device which relies on gravity and has no other parts to assure it functions properly. One other important note: anti-siphon valve back flow vales can not be tested to see if the backflow prevention is functioning, however, backflow devices purchased separately to be used with inline valves can be tested to assure they are functioning correctly. Using inline valves is a more professional way of installing your sprinkler system.

Globe Valves

Globe valves once had a spherical body, but modern globe valves have changed in shape, and only the name remains. Water flows through the valve without changing direction. The two halves of the valve body are separated by an internal baffle. A movable plug, or disc, screws in to shut off the valve. In manual globe valves, the plug connects to a stem which operates by hand wheel. In automatic globe valves, the stem is smooth.

Angle Valves

Named for their angular design, angle valves direct the flow of water at a right angle to the valve. Water flows into the valve, then changes direction 90%.

The Valve Manifold

The manifold is a group of control valves attached to a pipe. Water enters the manifold from the main water supply line. The water is then routed through the control valves. The valve manifold may be below or above ground.

To build the valve manifold, use a length of PVC pipe. Space the valves about three to six inches apart. The number of valves determines the overall length of the manifold pipe. Include an extra connection or two, for possible expansion to the system later. Save time and work by purchasing a ready-to-install manifold kit, which includes the sprinkler valves and all necessary parts and instructions. Many manifold kits have a flow control feature, to help conserve water.

Valve Boxes

A valve box is a plastic cover that protects the valves and wiring from damage and debris. Above ground, the valve box also protects the valves and manifold piping from harsh sunlight and inclement weather, or damage by accident, animals or vandalism.

Backflow Prevention Devices

Backflow prevention devices will prevent irrigation water from lawn sprinkler systems from backing up into the drinking water. Irrigation water may contain contaminants such as pesticides and other chemicals, as well as waste products and dirt. While these elements don’t harm the lawn, they create health risks in public or household drinking water.

Jul 2 2010

What are the Best Sprinkler Heads? Who Manufactures the BEST?

When you design your own DIY irrigation system, you probably want to know which brand of irrigation system supplies is the better one to buy. Both Hunter and Rain Bird make very good rotors and spray heads.

If you go with Hunter, make sure you use the Pros series or the Institutional series sprays for areas under 15 feet radius, and as far as their rotor models You can not go wrong with the PGP series, or I-20 series rotors.

If you go with Rain Bird, make sure you use 1800 series sprays for smaller areas (less than 15 feet radius) and as far as their rotor models You can not go wrong with the Rain Bird 5000 series or the 5000 Plus Series Rotors.
