Installing Low Voltage Outdoor Lighting


shutterstock_102514823

Before starting your outdoor lighting project make sure electricity is off or unplugged before setting up your lighting. The easiest lights to install are solar powered lights, no cables are required, and they usually come pre assembled. If you do not think that you will receive enough light throughout the year, or that your lights will be placed somewhere very shaded, to use solar powered outdoor lighting then the conventional lighting with cables will work best for you.

A kit is the easiest way to start if you are using a conventional wire connecting system. They usually come with everything you need, sometimes including a GFCI. GFCI (Ground Fault Circuit Interrupter) this provides extra shock protection or if you don’t have a GFCI you can use a regular outdoor outlet.

shutterstock_150468296

Steps to installing a cable connected outdoor lighting system:

  • Connect all of the pieces for each light before laying them out.
  • Lay out the lights as you would like them, without staking them into the ground.
  • Lay out the cable and connect the light to the cable with the connector cap, so that the cap punctures the cable and makes contact with the wire.
  • Dig a narrow trench along the cable path, connect the cable to the power pack and then plug the power pack into the GFCI or outlet.

*If any lights are not working double check the connectors.*

LX_300_SS_2

Another great product to have is a control transformer. These transformers provide you with the current time, photocell, function, and line output readouts. A great one is the LX-300SS 300 Watt Digital Lighting Control Transformer. The LX provides an active load bar displaying usage in 10% increments.

Easy to read both day and night the LED screen is high quality. Easy to set up and can be used as a standalone unit or added to an existing system for more power. Pick up an LX Transformer here. Check out Sprinkler Warehouse’s assortment of outdoor lights here.



Common Mistakes:

  • Make sure you position the lights so that you see the effect not the fixture.
  • Not placing lights where they are needed, such as pathways or the driveway.

shutterstock_145088929
